Wind Turbine Generator 400W CE & RoHS approved high-efficiency wind turbine max 600W permanent magnet

Regular price $415.80 $0.00 Unit price per
Shipping calculated at checkout.



Product Features / Advantage:

Wind turbine generator can transfer wind power to electrity. Wind is an important renewable resources. To meet most of customers' requirements, we promote an economy wind turbine generator which is cheap and good quality. Considering the generator can start easily, our engineers develop the lower start-up wind speed. Start the wind turbine generator only needs 2m/s wind speed. 20-year long life-span wind power generator is deserved you to own it.



1. 2m/s low wind speed starts the wind turbine generator.

This is the most obvious advange of this wind generator in all of same level product on the market which make high wind energy utilization rate.


2. Three phase AC output

Three phase output can make wind turbine transfer more wind power to electricity. 12V or 24V AC for customers' choise for their system.


3. Low fault and strong ability to resist the Typhoon

Fan adopts the unique design of the fuselage shock smooth operation, no noise, the blades with nylon composite materials manufacturing and become, with the optimization of aerodynamic design and structural design, start wind speed is low, high wind energy utilization coefficient, increase the power generating capacity. Stern rudder adopts the design of automatic yaw, stronger ability to resist the typhoon, safe and reliable operation.


4. Horizontal shaft function.

The wind turbine generator can adjust the angle automatically according to the wind directions by the horizontal shaft design.


5. 20-year long service life.

Due to the motor internal labyrinth design, external all fasteners are high strength stainless steel products, so it has better protection effect, can waterproof (IP65), prevent sand more effectively.


6. Structure is simple and reliable, beautiful appearance, strong mobility.

7. Easy installation



8.Tech Parameters


AC Output Wind Turbine Generator








































































































































Model No. Item WHX1.2-300 WHX1.3-400 WHX1.4-500 WHX1.4-600
Power Rated 300W 400W 500W 600W
Max 450W 600W 720W 830W
Voltage Rated

12/24 AC


Braked

14.4/28.8 AC


Rotor diameter mm 1200mm 1300mm 1350mm 1400mm
Rated Rotate Speed r/min 900r/min
Start-up wind speed m/s 2m/s
Cut-in wind speed m/s 2.6m/s
Rated wind speed m/s 12m/s
Cut-out wind speed m/s 50m/s
Yaw fixed-wing type
Engine

Type


Three-phase permanent magnet generator (Containing rare earth materials)

Structure


Horizontal shaft
Equipment surface protection Aluminum oxide+plastic coating
Body Material Die casting aluminum,one die casting forming
Blade Number 3PCS/5PCS (Optional)
Blade material High strength Carbon fiber with nylon
Pole diameter mm 48mm
Life span years 20years
Equipment surface protection Aluminum oxide+plastic coating
Working temperature - 40°C to + 60°C
Package Weight G.W 8.6Kgs 9Kgs 10Kgs 10.5Kgs
Package dimension LxWxH 69X32X24CM 69X32X24CM 69X32X24CM 69X32X24CM




Application
