Boguang flexible solar panel 20w panels solar cells cell module DC for car yacht light RV 12v battery boat 5v outdoor charger

Sale price $38.00 Regular price $38.00

Tax included.

Youtube Video

lanse miaosu-1_

Maximum power(Pmax)                            20W

Output tolerance                                      + 3%

Maximum system voltage                        700V DC

Open circuit voltage(Voc)                         21.6V

Short circuit current(Isc)                           1.22A

Maximum power voltage(Vmp)                 18V

Maximum power current(Imp)                    1.11A

Cell efficiency                                           19.6%

Operating temperature(NOCT)           45±2℃

Temperature range                                 -20℃~+80℃

Number of cells                                       36pcs

Weight                                                     0.49 KG

Size                                                         420*330*3 mm

Standard Test Conditions : lrradiance 1000w/m2,Temperature 25℃,AM=1.5


1. Normally we use standard base board, but the colour might be tiny different because of different producing batch.
2. To achieve a certain parameter, the arrangement of the solar cell silicon wafers might be with tiny difference, but the specification is the same as described.
3. The solar cell panel will be covered by PE film, some may with air bubble under the film, it will not effect the performance, you can remove the film, just like the film on the cellphone panel.
4. The colour of silicon solar cell is blue or black.

5. As solar panel, the sunlight strength will effect the performance of the solar cell, please use it in good sunlight.



1.semi flexible: can be bending angle up to 20 degrees

2.Durable with TPT backsheet, no glass

3.Light weight,easy carrying,easy shipment,easy installation

4.Thin : the thickness is only 3mm, easy joint to your yacht or RV roof , boat etc

5.Can be stepped on with soft soled shoses

6.make with high efficiency   Monocrystalline silicon   and solar panel up to 23%

7.more compack size generate 30% high power than market solar panel , steady perfect generate power performance ,

8.Rounding corners to prevent from being scratched

9.Hardening process surface prevent from scratched

10.easy installed with clue , adhesive, screw,and also grommet at corner is easy for installation

11.wide use applications:Golf car,Yacht, boat,caravan, electric car,travel tourism car, patrol car, roof,camping,roof power generations,tent,portable bag , backpacks , portable generator kits etc.

12..charge for 12v battery,Solve the problem that the car can't start due to lack of power.


Packing listing

1. 1*20W solar panel

2. 1* DC +alligator clip cable

3. 1*DC+Cigarette lighter  cable
