EASUN POWER 3KVA 24V 110VAC Grid Tie Solar Inverter 2000W 80A MPPT Solar Charge Pure Sine Wave Hybrid Inverter 40A AC Charge

Regular price $1,019.73

Tax included.



MODEL IGrid SV LV-3K-24
Max. PV Array Power 2000W
Maximum PV Array Open Circuit Voltage 145 VDC
MPPT Range @ Operating Voltage 30 VDC ~ 115 VDC
Number of MPP Tracker 1
GRID-TIE OPERATION
GRID OUTPUT (AC)
Nominal Output Voltage 110/120 VAC
Rated Output Power 2400W
Output Voltage Range 88~127 Vac VAC*
Nominal Output Current 27 A
Power Factor >0.99
EFFICIENCY
Maximum Conversion Efficiency (DC/AC) 90%
OFF-GRID, HYBRID OPERATION
GRID INPUT
AC Start-up Voltage / Auto Restart Voltage 60 - 70 VAC / 90 VAC
Acceptable Input Voltage Range 95-140 VAC
Maximum AC Input Current 40A
BATTERY MODE OUTPUT (AC)
Nominal Output Voltage 110/120 VAC
Rated Output Power 2400W / 3000VA
Output Waveform Pure Sine Wave
Efficiency (DC to AC) 93%
BATTERY & CHARGER
Nominal DC Voltage 24 VDC
Maximum Charging Current (from Grid) 60A
Maximum Charging Current (from PV) 80A
Maximum Charging Current 140A
GENERAL
PHYSICAL
Dimension, D X W X H (mm) 120x295x505
Net Weight (kgs) 11.5
INTERFACE
Parallel-able Yes. Single phase, Split phase
External Safety Box (Optional) Yes
Communication USB/Dry-Contact
ENVIRONMENT
Humidity 0 ~ 90% RH (No condensing)
Operating Temperature 0 to 50°C

EASUN POWER 110V Grid Tie Solar Inverter 6KVA 24V Inverter 4000W MPPT Inverters Pure Sine Wave Hybrid Inverter 40A AC Charger_09EASUN POWER 110V Grid Tie Solar Inverter 6KVA 24V Inverter 4000W MPPT Inverters Pure Sine Wave Hybrid Inverter 40A AC Charger_10



PAYMENT/SHIPPING

  • Import duties, taxes and charges are not included in the item price or shipping charges. These charges are Buyer’s responsibility.
  • Please check with your country customs office to determine what these additional costs will be prior to bidding/buying.



Shipping Notice:

1) Personal / Company Tax Code

According to international customs requirements, below country customer should provide their Tax code information. Otherwise, the goods will not be released by local customs. Please  kindly understand . Thank you

Brazil:CPF No. / CNPJ No.

ItalyFiscal Code No.

Germany:EORI No.

ArgentinaValue Added No.



2) Remote area addition fee FedEx & DHL

A Remote Area is defined as a post code or in the absence of post code, a suburb /town name that is difficult to serve. A delivery to one of the following post codes and towns would attract a Remote Area surcharge.

For Import Express shipments, a pickup from one of the same post codes and towns would attract a Remote Area surcharge. Please refer to your service guide for the surcharge amount in local currency





WARRANTY/QUALITY:

  • CE certified.
  • 100% QC before shipment.
  • Standard 1 year product warranty
  • Warranty will cover only items that are deemed to fail under normal usage. Accidental damage due to environmental causes or incorrect usage and installation will not be covered in warranty (but still serviceable
  • we will provide free pcb board during the warranty,but buyer need to pay for the shipment fee.
  • Contact us directly for warranty issues
  • Buyer is responsible for warranty return shipping.
